BQ-S 400

Download
Standby connection
380-420 VAC, 50-60 Hz, 63-125 A, IT/TN
Charge connection - CEE
380-420 VAC, 50-60 Hz, 63-325 A, IT/TN
Charge connection - power lock
380-440 VAC, 50-60 Hz, 200 A, IT/TN
380-480 V, 50-60 Hz, IT/TN
380-440 V, 50-60 Hz, IT/TN
208-240 V, 50-60 Hz, IT/TN
Discharge connection - CEE
400 V, 50 Hz, 16 A, 32 A, 63 A, 125 A, TN
Extra battery connection
800-1100 VDC, 500 A
Nominal energy
442 kWh
Available energy
350 kWh
Nominal apparent power
200 kVA (208-240 V), 315 kVA (380-480, 660-690 V)
Max. apparent power
200 kVA (208-240 V), 400 kVA
Overload
140 (<1min)/160 (<2sec) %/min
Nominal round-trip efficiency (IEC 62933-2-1)
>82 %
IP degree
IP56
Ambient conditions
-20 to +40 °C
Cooling/heating
Air cooled (air/air)
Fire extinguishing
Internal nozzles with connection from the outside
Detection
Fire
Housing type
Container
Dimensions [LxWxH]
3163 x 2438 x 2896 mm
Corrosion level
C5
Noise (low-high)
1m distance 63-78 dBA
Weight
Up to 8900 kg

Details are given for guidance only. Exact equipment may vary according to geographical location and availability.

  1. <45min drift
