Generator XQ1700 Norsok offshore
Last ned
Specifications
Frequency
50 / 60 Hz
Prime power
400/230 I 480/277 V
Prime power capacity
1
1500 / 1700 kVA
1200 / 1360 kW
Output
2
2167 / 2047 A
Breaker 4P
2500 A
Internal fuel tank
1650 L
Fuel consumption
3
236/258 I 269/297 L/hr
Fuel type
Diesel, GTL, HVO
Running time
7 / 6 hr
Dimensions [LxWxH]
6058 x 2438 x 2896 mm
Weight (without fuel)
4
22500 kg
Weight (incl. fuel)
4
24000 kg
Sound level
5
85 dB(A)
Remote monitoring
Yes
Details are given for guidance only
- Performance data quoted in accordance with ISO 8528-1
- Amps 50Hz at 400V, 60Hz at 480V
- Fuel consumption measured at 75% load. Fuel density is 850 G/L
- Includes oil and coolant, excludes slings. (including offshore frame on XQ250 and XQ500)
- Sound levels given at 75% prime power load 50 Hz at 7m, Sound data 60 hz is estimated 2 dBa more then 50 hz based on bare engine data
