Chiller EC100
Download
Specifications
Cooling capacity (at +30 ambient)
1
105 kW
Built-in pump
Yes
Power supply
400V/3Ph/50Hz/PE
Power connection
CEE 125A (5-pole)
Power consumption (at +30 ambient, excl. pump)
30.1 kW
Pump power (Max.)
5.5 kW
EER (excl. pump) (at +30 ambient)
1
3.49
Power protection (fuse)
125 A
Hydraulic connections (DIN11851)
50 DN [mm]
Maximum starting current
17 A
Fluid temperature range
-10 / +12 °C
Dimensions [LxWxH]
3240 x 1200 x 2110 mm
Weight
1895 kg
Forklift pockets
Yes
Max. sound pressure @ 10m
52 dB(A)
Recommended Pon Energy Rental genset size
135 kVA
Details are given for guidance only
- Based on 12/7°C water temperature, 30°C air ambient.
- Cooling capacity based on 12/7°C water temperature, 35°C air ambient. EUROVENT conditions.
